28
SPECIFICATIONS / SMART DIAGNOSIS™ SYSTEM
Should you experience any problems with your
washing machine, it has the capability of transmit-
ting data via your telephone to the Smart Diagno-
sis Team. This gives you the capability of speaking
directly to our specially trained technicians. The
technician records the data transmitted from your
machine and uses it to analyze the issue, providing a
fast and effective diagnosis.
If you experience problems with your washer, call
1-800-243-0000 (1-888-542-2623 in Canada). Only use
the Smart Diagnosis System feature when instructed to
do so by the Smart Diagnosis Team. The transmission
sounds that you will hear are normal and sound similar
to a melody.
Smart Diagnosis cannot be activated unless your
washing machine can be turned on by pressing the
POWER button. If your washing machine is unable
to turn on, then troubleshooting must be done with-
out using Smart Diagnosis.
USING THE SMART DIAGNOSIS™ SYSTEM
Follow the technician’s instructions and perform the following steps when requested.
HOLD the mouthpiece of your phone over the power button, when instructed to do so by the call center, no more than
one inch from (but not touching) the machine.
NOTE: Do not press any other buttons or turn the cycle selector knob.
PUSH and hold the Wash Temp. button while continuing to hold your phone to the POWER button.
LISTEN for three beeps. After you hear the three beeps, release the Temp. button. Keep the phone in place until the
tone transmission has finished. The display will count down the time. Once the countdown is over and the tones have
stopped, resume your conversation with the technician, who will then be able to assist you in using the information
transmitted for analysis.
SPECIFICATIONS
Model WT1150C*
Description Top-Loading Washer
Electrical requirements 120 VAC @ 60 Hz.
Max. water pressure 20~120 psi (138~827 kpa)
Dimensions 27”(W) X 28 3/8”(D) X 40 3/8”(H), 55 3/8” (H with lid open)
68.6cm(W) X 72.1cm(D) X 102.6cm(H), 140.6cm (H with lid open)
Net weight 135.7 lbs. (61.5 kg)
Max. spin speed 1000 RPM
SMART DIAGNOSIS™ SYSTEM
Smart Diagnosis is a troubleshooting feature designed to assist, not replace, the traditional method of trou-
bleshooting through service calls. The effectiveness of this feature depends upon various factors, including,
but not limited to, the reception of the cellular phone being used for transmission, any external noise that
may be present during the transmission, and the acoustics of the room where the machine is located. Ac-
cordingly, LG does not guarantee that Smart Diagnosis would accurately troubleshoot any given issue.

Table of Contents

Questions and Answers:

LG WT1150CW Specifications

General IconGeneral
Styletop load
Colorwhite
Washer Capacity4.5 cubic feet
Max Spin Speed1000 revolutions per minute
Spin Speeds4
Number of Cycles9
Cycle Selectionspre wash+ normal, cotton/normal, tub clean, bulky/bedding, heavy duty, speed wash, delicates, bright whites™, waterproof
Optionssoak, extra rinse, fabric softener, delay wash, child lock, signal, rinse+spin, spin only, coldwash™, water plus
Temperature Settings5
Temperature Selectionsextra hot, hot, warm, cold, tap cold
Soil Levelslight, normal, heavy
Delay Start / Endyes
Child Lockyes
Cycle Signalyes
Steamno
Dispensersingle load
Smart Homefalse, true
Annual Energy Consumption140 kilowatt hours
Voltage120 volts
Current5 amperes
Weight and Dimensions IconWeight and Dimensions
Depth28.4 inches
Height40.1 inches
Width27 inches
Net Weight135.7 pounds
