Linksys MAX-STREAM MR8300 User Manual

4
The light on the top of your router gives you information about the router’s operation.
Normal Operation
WPS
Blue (blinking) Pairing started
Yellow (blinking) Pairing unsuccessful
Blue Pairing successful
Light description Status
Blue (blinking)
Starting up
Wait for the router to finish starting up.
Purple
Ready for setup
Open the Linksys app to complete setup.
Purple (blinking) Setup in progress
Follow instructions in the app.
Blue
Connected to internet
Router is online, everything is good.
Red
No internet
Not online, check with your ISP for service interruptions.
Red (blinking)
Not plugged in to modem
Make sure your router is firmly connected to the modem.

Linksys MAX-STREAM MR8300 Specifications

General

Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, Status, USB, WLAN
Wall mountable	Yes
DSL WAN	-
WAN connection type	RJ-45
Antennas quantity	4
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	- Mbit/s
WLAN data transfer rate (first band)	400 Mbit/s
WLAN data transfer rate (second band)	867 Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Flash memory	256 MB
Internal memory	512 MB
Processor frequency	716 MHz
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Security algorithms	128-bit AES, WPA, WPA2

Weight and Dimensions

Depth	213.7 mm
Width	161.8 mm
Height	54.8 mm
Weight	608 g
