Lippert Components Level-Up User Manual

Rev: 12.27.2017
Page 19
LCI Level-Up Motorized Leveling Winnebago Industries up to 9-2015 Owner's
Description Part # Details Quantity
Power Unit
293414 Hydraulic Power Unit, Leveling Only 1
293559 Hydraulic Power Unit, Leveling Only 1
Motor
179327 12VDC Motor for Power Unit 1
Solenoid
161394 Motor Solenoid 1
Valve
177094 Blocking Valve 4
Coil
174184
Electromagnetic Coil for Blocking
Valve
5
Pressure Switch
142927 2150 PSI Rated Pressure Switch 1
Pump Harness
178373 Electrical Harness for Power Unit 1
Main Harness 285307
Master Feed to Electrical
Components
1
Remote Sensor Harness
241314 Remote Sensor to Brain Harness 1
Controller 289252 Control Module 1
Touch Pad
234802 Touch Pad mounted in Dash 1
Rear Sensor 294287
Secondary Level Sensor mounted
rearward
1
Hydraulic Jacks
433458 8k Leveling Jacks *
236560 14k Leveling Jacks *
258550 20k Leveling Jacks *
Footpad
113309 9” Footpad for Leveling Jacks 4
117238
12” Footpad for Leveling Jacks -
Optional
**
Hardware Kit 176556 Hardware Kit
Main Harness 178375 30' Main Harness
Interconnect Harness
178372
21’ Power Unit to Controller
Harness
1
Fitting
141109 Straight Fitting 2
141610 Elbow Fitting 8
162838 Washer 16
196994 Bolt 16
*Jack quantities will either be 2 or 4 depending on OEM specified design.
**Optional - Quantities will vary.
Bill of Materials
