LCI Level-Up Motorized Leveling Winnebago Industries up to 9-2015 Owner's
Troubleshooting Guide
What Is Happening? Why? What Should Be Done?
System will not turn on
and on/off; indicator
light does not illuminate.
Coach Ignition not in RUN
position.
Turn ignition to RUN position.
Controls have been on for
more than four minutes
and have timed out.
Turn ignition OFF and then back
ON.
Touch Pad turns on
but turns off when leg
button is pushed or
displays “low voltage”.
Low Voltage on battery. Start coach to charge battery.
Touch Pad turns on,
coach will not auto-level,
“jacks down” displayed,
jacks are retracted.
Low fluid Level.
Check fluid level in reservoir,
if fluid is low add fluid to
½
”
from top of reservoir with jacks
retracted. If "JACKS DOWN" light
remains on, call Lippert Service.
Jacks will not extend
to ground, pump is
running.
Little or no fluid in
reservoir.
Add fluid as recommended; See
page 16.
Valve is inoperative. Clean, repair, or replace.
Electronic signal is lost
between controller and
solenoid.
Trace wires for voltage drop or
loss of and valves signal. Repair or
replace necessary wires or replace
control pad.
Any one or two jacks will
not retract.
Hose damaged or
unconnected.
Replace with new hose or
reconnect hose.
Valve inoperative. Replace inoperative valve.
Electronic signal is lost
between controller and
solenoid.
Attempt to retract jacks in
MANUAL mode. If successful,
replace touch pad; if not, test for
voltage drop between touch pad
and valve repair bad wiring or
replace defective board or valve.
“READY - Jacks: Up” does
not display when all
jacks are retracted.
Low fluid level.
Add fluid as recommended; See
page 16.
Retract pressure switch
inoperable.
Check connection or replace.
Alarm sounds and
“jacks down” light starts
flashing while traveling;
jacks are fully retracted.
Low fluid level.
Add fluid as recommended; See
page 16.
Retract pressure switch
inoperable.
Check connection or replace.
Coach bleeds down after
jacks are extended.
Jack bleeds down after
being retracted.
Possible fluid leak.
Check for fluid leaks and repair or
replace components as necessary.
Valve Manual Override
open.
Close Override, See pg. 14, Fig 8.
Touch Pad powers up;
screen displays “low
voltage”.
Loose ground wire at
power unit.
Check for loose wires.
Engine not running. Start coach engine.
No power to touch pad.
Tripped circuit breaker. Reset.
125 amp fuse blown. Replace fuse.
Ignition not ON. Turn ignition ON.
Auto level function does
not finish.
Error code "Unable to
finish leveling."
Move coach to a more level site.
