GB
7
Preparation
Front / Top / Side View and Controls
Item Description
1 IR (Infrared Receiver)
Receives IR signals from the remote control.
Do not put anything near the sensor, as its function may be affected.
2 POWER LED
Illuminates blue when the TV is turned on. Illuminates red when the TV is in standby
mode.
3 POWER ON/OFF Switch on the POWER ON/OFF switch to turn the TV to standby mode.
4
Press to eject disc. (DVD mode)
5
Press to start playback or pause. (DVD mode)
6 VOL + / –
Adjusts the volume.
Press to select and adjust a setting in the OSD menu.
7 CH + / – Press to select a channel or select a sub-menu from the OSD menu.
8 MENU Displays the OSD (on screen display) menu.
9 SOURCE
Press to select among different input signal sources:
DTV / ATV / DVD / AV / SCART / YPBPR / HDMI1 / HDMI2 / PC / MEDIA.
Confirmed the selection on OSD menu.
10
/ I
Switches the TV on from standby mode.
Switches the TV back to standby mode.
11 Disc Slot
Insert the disc with the label side backwards you (12 cm discs only. Don't insert 8 cm
discs)
1 2
3
11
4 5 6 7 8 9 10
L24DVDB11_IB_110429.indd 7 29/04/2011 5:10 PM
