* All images are for indication only; please refer to your individual unit for actual item.
Removing the Oven Door Glass for Cleaning
1. Open the oven door.
2. Remove the plastic vent on top of the
door by gently pulling at each end.
3. Carefully slide the glass out. Be aware
that once the glass is removed the door
may spring up.
4. When replacing the glass make sure
you place it back with the painted side
down. Slide the glass back into place
and clip the plastic vent back on.
