8
Control Panel
1. Grill Control
2. Oven Control
3. Rear Left Burner (Standard) Control
4. Front Left Burner (Large) Control
5. Front Right Burner (Small) Control
6. Rear Right Burner (Standard) Control
7. Oven Light Switch
8.
Ignition Switch
Gas Burners
The relevant controls adjust the flow of gas through each of the burners.
•
= OFF
•
= Minimum Flame
•
= Maximum Flame
You can cook at any heat setting between
and , but never between and the OFF position.
1 2 3 4 5 6 7
8
* All images are for indication only; please refer to your individual unit for actual item.
