Lumens DC125 User Manual

English - 39
Chapter 7 Descriptions of major
functions – Windows User
7.1 I would like to optimize the image
 Auto Operation: Click .
 Manually enabled function: Press the AF [FOCUS] button on the camera
head of main unit.
7.2 I would like to freeze the live image
 Click to freeze the live image of Ladibug™.
 Click
once again to lift the freeze.
7.3 I would like to turn on/off the lamp
 Click to turn on/off the camera lamp.
7.4 I would like to adjust the brightness
 Click to open the brightness scroll.
 Move rightward to increase brightness, or leftward to decrease
brightness.
7.5 I would like to capture images
 Click to capture images.
<Note> When the images are captured, please view the images on
the image browser page

Lumens DC125 Specifications

General

Sensor type	-
Image freeze	No
Maximum frame rate	30 fps
Optical sensor size	- \
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1600 x 1200 (UXGA), 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA)
Optical zoom	8 x
Shooting area (WxD)	400 x 300 mm
Lamp type	LED
Photo effects	Mirror
Product color	Red
Cable lock slot	Yes
Cable lock slot type	Kensington
Image quality adjustment	Sharpness
Interface	USB 2.0
Power supply type	USB

Weight and Dimensions

Depth	236 mm
Width	106 mm
Height	280 mm
Weight	1200 g
Dimensions folded (WxDxH)	236 x 106 x 280 mm
