Lutron Electronics AM-4206M User Manual

Each digit indicate the following status :
D0 End Word
D1 to D8 Display readin
g
, D1=LSD, D8=MSD
For example:
If the display readin
g
is 1234, then D8 to D1 i
s
00001234
D9 Decimal Point(DP) for display.
0 = No DP, 1= 1 DP, 2 = 2 DP, 3 = 3 DP
D10 Polarity
0 = Positive 1 = Ne
g
ative
D11 & D12 Annunciator for Display
01
=
C 09 = Knot 12 = mile/h
02
=
F 10 = Km/h 84 = CMM
08 = m/s 11 = ft/min 85 = CFM
D13 When send the upper display data = 1
When send the lower display data = 2
D14 4
D15 Start Word
6. BATTERY REPLACEMENT
1)
When the left corner of LCD display show " LBT ", it is
necessary to replace the battery. However in-spec
measurement may still be made for several hours after
low battery indicator appears before the instrument
become inaccurate.
2) Slide the Battery Cover ( 3-16, Fig. 1 ) away from the
instrument and remove the battery.
3) Install a 9 V battery (PP3 type) and replace the cover.
10
0507-AM-4206M
