Lutron Electronics AM-4206M User Manual

Data Output RS 232 PC serial interface.
Power Supply Alkaline or heavy duty type DC 9V battery,
006P, MN1604 (PP3) or equivalent.
Power Current Approx. DC 8.3 mA.
Weight 381 g/0.84 LB, main instrument
Dimension Main instrument : 180 x 72 x 32 mm
Sensor head: Round, 72mm Dia.
Accessories Instruction manual.....................
.
1 PC.
Included Sensor probe.............................
.
1 PC.
Carryin
g
case............................. 1 PC.
Optional Data acquisition software........
.
SW-U801-WIN
Accessories USB cable..............................
.
USB-01
RS232 cable...........................UPCB-01
2-2 Electrical Specifications
A. Air velocity
Measurement Ran
g
e Resolution Accuracy
m/s 0.4 - 35.0 m/s 0.1 m/s ±(2%+0.2m/s)
0.01m/s,<10m/s
km/h 1.4 - 126.0 km/h 0.1 km/h ±(2%+0.8km/h)
mile/h 0.9 - 78.3 mph 0.1 mile/h ± (2%+0.4mile/h)
knots 0.8 - 68.0 knots 0.1 knots ±(2%+0.4knots)
ft/min 79 - 6890 ft/min 1 ft/min ± (2%+40 ft/min)
Remark : For prolon
g
ed life and safe operation, if
measurin
g
ran
g
e > 30 m/s please do not make th
e
operation over 5 minutes continuously.
B. Air flow
Measurement Ran
g
e Resolution Area
CMM ( m^3/min. ) 0-999,900 m^3/min. 0.001-100 0.001-9,999 m^2/min.
CFM ( ft^3/min. ).0-999,900 ft^3/min. 0.001-100 0.001-9,999 ft^2/min.
C. Air temperature
Measuring Range 0 to 80 /32 to 176 ℃℃℉ ℉
Resolution 0.1 /0.1 ℃℉
Accuracy 0.8 /1.5 ( < 60 )℃℉ ℃
3
