SPECIFICATIONS
Model: DLS714
Blade diameter 190 mm
20 mm or 15.88 mm
Max. kerf thickness of the saw blade 2.2 mm
Max. miter angle Left 47°, Right 57°
Max. bevel angle Left 45°, Right 5°
No load speed 5,700 min
-1
Dimensions (L x W x H) 655 mm x 430 mm x 445 mm
Rated voltage D.C. 36 V
Net weight 14.4 - 14.7 kg
without notice.
-
est combinations, according to EPTA-Procedure 01/2014, are shown in the table.
Applicable battery cartridge and charger
Battery cartridge BL1815N / BL1820B / BL1830B / BL1840B / BL1850B / BL1860B
Charger DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF /
DC18SH / DC18WC
• Some of the battery cartridges and chargers listed above may not be available depending on your region of
residence.
WARNING: Only use the battery cartridges and chargers listed above. Use of any other battery cartridges
Cutting capacities (H x W) with blade 190 mm in diameter
Miter angle Bevel angle
45° (left) 0° 5° (right)
0° 40 mm x 300 mm 52 mm x 300 mm 40 mm x 300 mm
45 mm x 265 mm
(NOTE 1)
60 mm x 265 mm
(NOTE 1)
–
45° (left and right) 40 mm x 212 mm 52 mm x 212 mm –
45 mm x 185 mm
(NOTE 2)
60 mm x 185 mm
(NOTE 2)
–
57° (right) – 52 mm x 163 mm –
– 60 mm x 145 mm
(NOTE 3)
–
1. Max. Cutting capacity when using a wood facing 20 mm thickness
2. Max. Cutting capacity when using a wood facing 15 mm thickness
3. Max. Cutting capacity when using a wood facing 10 mm thickness
