Makita Dolmar PS-510 User Manual

3
DCS460/
DCS461
DCS500
DCS501
DCS4600 DCS5000
DCS5001
DCS510 US
Stroke volume cm
3
45.6 49.9 45.6 49.9 3.1 cu. in
Bore mm 43 45 43 45 1.77 inch
Stroke mm 31.4 1.24 inch
Max. power at speed
3)
kW / 1/min 2.2 / 10,000 2.4 / 10,000 2.6 / 10,000 2.8 / 10,000 3.3 / 10,000
Max. torque at speed
3)
Nm / 1/min 2.7 / 7,000 2.9 / 7,000 2.8 / 7,000 3.1 / 7,000 2.9 / 7,000
Idling speed / max. engine speed with bar and chain 1/min 2,500 / 13,500 2,500 / 14,500 2.500 / 13,500
Clutch engagement speed 1/min 3.900
Sound pressure level at the workplace L
pA av
per ISO/CD 22868
1)
dB (A) 102.1 102.4 101.2 101 -
Sound power level L
WA av
per ISO/CD 22868
1)
dB (A) 108.3 108.8 109.1 108.6 -
Sound Pressure Level at the operator‘s ear
at full load according to ANSI B 175.1 dB (A)
- 103.9
Sound Pressure Level at the bystander‘s position
(50 ft/15 m distance) according to ANSI B 175.1 dB (A)
- 76.2
Vibration acceleration a
h,w eq
per ISO 22867
1)
- Tubular handle m/s
2
4.1 5.2 4.1 5.2 -
- Rear handle m/s
2
3.6 3.7 3.6 3.7 -
Carburetor (diaphragm, choke flap carburetor) Typ membrane carburetor ZAMA membrane carburetor
Ignition system Typ condenser ignition system electronic condenser ignition system
Spark plug Typ NGK BPMR 7A
Electrode gap mm 0.5
or spark plug Typ BOSCH WSR 6F
Fuel consumption at max. load per ISO 7293
3)
kg/h 1.1 1.2 1.3 1.2
Specific consumption at max. load per ISO 7293
3)
g/kWh 500 450 480
Fuel tank capacity l 0.47 15.9 floz
Chain oil tank capacity l 0.27 9.1 floz
Mixture ratio (fuel/two-stroke oil)
- when using DOLMAR oil 50 : 1 / 100 : 1 (HP-100) 50 : 1 50 : 1 50 : 1 / 100 : 1 (HP-100)
- when using Aspen Alkalyt 50 : 1 (2%) - 50 : 1 (2%)
- when using other oils 40 : 1 (JASO FC or ISO EGD) 40 : 1 40 : 1 40 : 1 (JASO FC or ISO EGD)
Chain brake engages manually or in case of kickback
Chain speed
2)
m/s 19.3 / 22.2 -
Sprocket pitch inch .325 oder 3/8
Number of teeth Z 7
Chain type see the Extract from the spare-parts list
Pitch / gauge inch .325 / 0.050, 0.058 oder 3/8 / 0.058 .325 / 0.050 oder 3/8 / 0.050
Guide bar, length of a cut cm 33 / 38 / 45 / 53 16 / 18 inch
Guide-bar type see the Extract from the spare-parts list
Weight (fuel tank empty, without chain, guide bar and accessories) kg 5.5 5.1 12.1 lbs
1)
Figures derived in equal part from idling, full-load and racing speed.
2)
At max. power
3)
For models without starting valve
TECHNICAL DATA

Makita Dolmar PS-510 Specifications

General

Brand	Makita
Model	Dolmar PS-510
Category	Chainsaw
Language	English
