[3] TIGHTENING TORQUE
Fastening for
Crank case underside 266608-2 45x40 Hexalobular tapping screw
Part No. of Screw/ Bolt/ Clutch Description Quantity Fastening torque (N.m.)
10 ± 0.5
Intermediate flange 266651-1 25.5x16 Hexalobular tapping screw 4 ± 0.5
Muffler base (the component of Muffler complete) 266605-8 2M5x16 Hexalobular socket head bolt 8 ± 1
Muffler cover (the component of Muffler complete)
and Cooling plate
266605-8 2M5x16 Hexalobular socket head bolt 8 ± 1
266606-6 1M5x40 Hexalobular socket head bolt 8 ± 1
Carburetor 266604-0 2M4x40 Hexalobular socket head bolt 3 ± 0.5
Clutch (M10 -1.0 thread pitch/ Left hand thread) 168607-9 1Clutch complete 35 ± 2.5
Ignition coil assembly 266631-7 2M5x20 Hexalobular socket head bolt 5 ± 0.5
Flywheel 264053-5 1M8x1 Hex nut 22.5 ± 2.5
Tubular handle 266651-1 45.5x16 Hexalobular tapping screw 4 ± 0.5
Spark plug 168599-2/ 168401-9 1Spark plug 11 ± 2
Contact spring 266421-8 13x10 Tapping screw 1 ± 0.2
