WARNING:
This chain saw is capable of severe kickback that coult result in serious injury to the user. Do not operate this chain
saw unless you have extraordinary cutting needs and experience and specialized training for dealing with kickback.
Chainsawswithsignicantlyreducedkickbackpotentialareavailable.
Technical data
EA3500S EA3501S
Stroke volume cu. in (cm)
3
2.1 (35)
Bore inch (mm) 1.50 (38)
Stroke inch (mm) 1.20 (30.6)
Max. power at speed kW / 1/min 2.3 / 10,000
Max. torque at speed N·m / 1/min 2.0 / 7,000
Idling speed/max. engine speed with bar and chain rpm 2,800 / 13,100
Coupling speed rpm 4,100
Sound pressure level at the operator´s ear
according to ISO 22868
dB (A) 101.7
Carburetor Type diaphragm carburator
Ignition system Type electronic
Spark plug Type NGK CMR6A
or spark plug Type --
Electrode gap inch (mm) .023 (0.6)
Fuel consumption at max. load per ISO 7293 kg/h 0.68
Specicconsumptionatmax.loadperISO7293 g/kWh 500
Fuel tank capacity oz 13.5
Chain oil tank capacity oz 9.5
Mixture ratio (fuel/two-stroke oil)
- when using MAKITA synthetic oil 50 : 1
- when using other synthetic oils
50 : 1
(oil quality must be JASO FC or ISO EGD)
Chain brake engages manually or in case of kickback
Sprocket pitch inch 3/8
Number of teeth Z 6
Weight
(fuel tank empty, without chain, guide bar and accessories)
lbs 9.70 9.92
(For Canada)
NOTE: This spark ignition system complies with the Canadian standard ICES-002.
Saw chain and guide bar
Saw chain type 492 (91PX) 290 (90SG), 291 (90PX)
Pitch inch 3/8”
Gauge inch (mm) 0.050” (1.3) 0.043” (1.1)
Guide bar type Sprocket nose bar
Guide bar, length of a cut inch (mm) 12” (300) 14” (350) 16” (400) 12” (300) 14” (350)
No. of drive links 46 52 56 46 52
WARNING: Use appropriate combination of the guide bar and saw chain. Otherwise personal injury may result.
