Makita EK7651H User Manual

3
You will notice the following symbols on the saw and in the Instruction Manual:
Symbols
Read instruction manual and follow the
warning and safety precautions!
Cutting disc dimensions
Particular care and caution! Engine-Manual start
Forbidden! Stop engine!
Wear protective helmet, eye and ear
protection, and respiratory protection!
Warning! Kickback!
Wear protective gloves! Fuel (Gasoline)
No smoking! First Aid
No open re! Recycling
Direction of cutting wheel rotation
WARNING: the max. peripheral
speed of the cutting disc is 80 m/s!
1
2345
Delivery inventory
1. Power Cutter
2. 13/19 AF combination wrench
3. Star-shaped wrench
4. Carburetor adjustment screwdriver
5. Adapter ring (Tools for some countries may not require this
ring.)
6. Instruction manual (not shown)
In case one of the parts listed should not be included in the
delivery inventory, please consult your sales agent.

Makita EK7651H Specifications

General

Depth	780 mm
Width	310 mm
Height	455 mm
Weight	12900 g
Product type	Petrol abrasive saw
Product color	Black, Blue
Sound power level	104.6 dB
Cutting speed	80 m/s
Blade diameter	350 mm
Idle speed (max)	4300 RPM
Cutting depth (90º)	122 mm
Sound pressure level	92.7 dB
Sound level uncertainty	2.5 dB
Engine type	4-stroke engine
Engine power	4.1 hp
Uncertainty K	2 m/s²
Fuel tank capacity	1.1 L
Vibration emission	2.7 m/s²
Engine displacement	75.6 cm³
Arbor diameter	20 mm
Idle speed (min)	9100 RPM
Anti-vibration system	Yes
Engine number of strokes	4
Air filtration stages quantity	5
Motor power	4.5 hp
Power source	Gasoline
Motor rated power	3.3 kW
