Makita ER2600L User Manual

6
TECHNICAL DATA
Model ER2600L
Handle type Loop handle
Dimensions: length x width x height (without cutting tool)
1,645 x 220 x 510 mm
(64-3/4” x 8-5/8” x 20”)
Net weight 4.3 kg (9.5 lbs)
Engine type Air cooled, 2-stroke, single cylinder
Engine displacement 25.7 cm
3
(1.57 cu. in.)
Maximum engine performance 0.83 kW
Maximum rotational frequency of the spindle 8,000 /min
Cutting diameter with nylon cutting head φ 400 mm (15-3/4”)
Idling speed 3,000/min
Clutch engagement speed 4,100/min
Fuel
Mixed gas
Gasoline: Two-stroke Engine Oil = 50:1
Volume (fuel tank) 0.6 L (36.6 cu. in.)
Carburetor WALBRO WYC
Spark plug NGK BPMR7A
Electrode gap 0.6 - 0.7 mm (0.024 - 0.028”)
(For Canada) NOTE: This spark ignition system complies with the Canadian standard ICES-002.

Makita ER2600L Specifications

General

Blade size	- mm
Blade type	Double blade
Product color	Black, Blue
Fuel tank capacity	0.6 L
Engine displacement	25.7 cm³
Engine power	830 W
Power source	Gasoline

Weight and Dimensions

Depth	1645 mm
Width	220 mm
Height	510 mm
Weight	4300 g
