INTRODUCTION 31000 LUFFING JIB OPERATOR MANUAL
1-2 Published 07-23-15, Control # 078-03
CRANE/ATTACHMENT/STRAP IDENTIFICATION
An identification plate is on the outside of the operator cab (Figure 1-1), on attachments (for example, luffing jibs), and on
straps available for this crane:
CRANE ORIENTATION
FIGURE 1-1
Operator cab Enclosure
FIGURE 1-2
These numbers (0°, 90°, 180°, and 270°)
represent the swing angle.
The current swing angle is shown on the RCL/
RCI system Working screen (see Folio Model
31000 2204 RCL/RCI Manual).
FRONT
0°
LEFT
270°
RIGHT
90°
REAR
180°
