Part Number 000015432 4/18 107
Wiring Diagrams
The following pages contain electrical wiring diagrams. Be
sure you are referring to the correct diagram for the ice
machine you are servicing.
n
Warning
Always disconnect power before working on electrical
circuitry.
Wiring Diagram Legend
The following symbols are used on all of the wiring
diagrams:
* Internal Compressor Overload
(Some models have external compressor
overloads)
** Fan Motor Run Capacitor
(Some models do not incorporate fan motor run
capacitor)
( ) Wire Number Designation
(The number is marked at each end of the wire)
—>>— Multi-pin Connection
(Electrical Box Side) —>>—
(Compressor Compartment Side)
Diagrams
