Manitowoc QuietQube SY3074C User Manual

Part Number 80-1505-3 6/11 249
IB0822DC/IB0824YC/CVD885 SERIES REMOTE
AIR COOLED MACHINES BEFORE SERIAL
NUMBER 110682385
NOTE: These characteristics may vary depending on
operating conditions.
CYCLE TIMES
24-HOUR ICE PRODUCTION
OPERATING PRESSURES
Freeze Time + Harvest Time = Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
Water Temperature °F/°C
50/10 70/21 90/32
-20 to 70/
-29 to 21
9.4-10.8 10.5-12.1 11.4-13.1
.75-2.5
80/27 9.5-11.0 10.7-12.3 11.4-13.1
90/32 10.3-11.9 11.2-12.9 12.1-13.8
100/38 11.2-12.9 12.3-14.1 13.3-15.2
1
Times in minutes.
Air Temp.
Entering
Condenser
°F/°C
Water Temperature °F/°C
50/10 70/21 90/32
-20 to 70/
-29 to 21
760 690 640
80/27 750 680 640
90/32 700 650 610
100/38 650 600 560
1
Based on average ice slab weight of 5.75-6.50 lb.
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
psig
Suction
Pressure
psig
Discharge
Pressure
psig
Suction
Pressure
psig
-20 to 50/
-29 to 10
215-260 46-22 140-185 70-95
70/21 220-270 40-23 150-190 70-100
80/27 225-285 47-24 155-195 80-95
90/32 235-295 52-25 165-200 85-100
100/38 260-340 56-26 180-210 85-112
110/43 300-385 60-28 195-230 90-115
