Manitowoc QuietQube SY3074C User Manual

252 Part Number 80-1505-3 6/11
SD1072C/SY1074C/CVD1085 SERIES REMOTE AIR
COOLED MACHINES BEFORE SERIAL NUMBER
110697654
NOTE: These characteristics may vary depending on
operating conditions.
CYCLE TIMES
24-HOUR ICE PRODUCTION
OPERATING PRESSURES
Freeze Time + Harvest Time = Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
Water Temperature °F/°C
50/10 70/21 90/32
-20 to 70/
-29 to 21
7.0-8.1 7.7-8.1 8.0-9.3
.75-2.5
80/27 7.2-8.4 7.9-9.1 8.7-10.1
90/32 7.5-8.7 8.2-9.5 9.1-10.5
100/38 8.4-9.6 9.3-10.7 10.3-11.9
110/43 9.4-10.8 10.5-12.1 11.9-13.6
1
Times in minutes.
Air Temp.
Entering
Condenser
°F/°C
Water Temperature °F/°C
50/10 70/21 90/32
-20 to 70/
-29 to 21
970 900 870
80/27 950 880 810
90/32 920 850 780
100/38 840 770 700
1
Based on average ice slab weight of 5.75-6.5 lb.
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
psig
Suction
Pressure
psig
Discharge
Pressure
psig
Suction
Pressure
psig
-20 to 50/
-29 to 10
200-250 38-25 175-235 70-85
70/21 230-255 38-25 185-235 70-85
80/27 235-260 44-27 190-240 70-90
90/32 240-290 52-28 200-250 85-100
100/38 275-345 58-29 225-260 90-110
110/43 310-380 62-31 240-290 100-115
