Part Number 000017542 Rev 00 8/22 17
Section 2 Installation Instructions
Maximum Breaker Size & Minimum Circuit Amperage Chart
Important
Due to continuous improvements, this information is
for reference only. Please refer to the ice machine serial
number tag to verify electrical data. Serial tag information
overrides information listed on this page.
Series Ice Machine
Voltage/
Phase/
Cycle
Air-Cooled Water-Cooled QuietQube®
Max
Fuse/
Circuit
Breaker
Min
Circuit
Amps
Total
Circuit
Amps
Max
Fuse/
Circuit
Breaker
Min
Circuit
Amps
Max
Fuse/
Circuit
Breaker
Total
Circuit
Amps
UNF0200 115/1/60 15 Amp — 7.5 — — — —
UNP0200 115/1/60 15 Amp — *7.5 — — — —
UFF0200 115/1/60 15 Amp — 7.5 — — — —
UFP0200 115/1/60 15 Amp — *7.5 — — — —
UFF0350 115/1/60 15 Amp — 10.0 — — — —
UFP0350 115/1/60 15 Amp — *10.0 — — — —
UNF0300 115/1/60 15 Amp — 10.0 — — — —
UNP0300 115/1/60 15 Amp — *10.0 — — — —
RFF0320 115/1/60 20 Amp 12.8 — — — — —
RFP0320 115/1/60 20 Amp *12.8 — — — — —
RNF0320 115/1/60 20 Amp 12.8 — — — — —
RNP0320 115/1/60 20 Amp *12.8 — — — — —
RNF0620 115/1/60 25 Amp 16.3 — 25 Amp 15.4 — —
RNP0620 115/1/60 25 Amp *16.3 — 25 Amp *15.4 — —
RFF0620
115/1/60 25 Amp 16.3 — 25 Amp 15.4 — —
208-230/1/60 15 Amp 8.7 — 15 Amp 8.2 — —
RFP0620 115/1/60 25 Amp *16.3 — 25 Amp *15.4 — —
RNF1100 RNF1020C
115/1/60 — — — — — 15 Amp 2.9
208-230/1/60 20 Amp 14.2 — 20 Amp 13.7 — —
RNP1100 208-230/1/60 20 Amp *14.2 — — — — —
RFF1300 208-230/1/60 20 Amp 12.5 — 20 Amp 12.5 15 Amp 1.4
RNF2000C RFF2200C 208-230/1/60 — — — — — 15 Amp 3.2
RFF2500 208-230/3/60 20 Amp 15.0 — — — — —
* Indicates preliminary data
NOTE: Maximum allowable voltage variation at compressor start-up is ±10% of voltage listed above and on the model/serial
plate.
QUIETQUBE® REMOTE CONDENSING UNIT
Condensing Unit Voltage/Phase/Cycle Maximum Fuse/Circuit Breaker Minimum Circuit Amps
RCUF1200
208-230/1/60 15 Amp 15
208-230/3/60 15 Amp 15
RCUF1000
208-230/1/60 15 Amp 15
208-230/3/60 15 Amp 15
RCUF2200 208-230/3/60 15 Amp 15
