GROVE Published 1-20-2017, Control # 468-02 1-1
CD5515-2/YB5515-2 OPERATOR MANUAL INTRODUCTION
SECTION 1
INTRODUCTION
SECTION CONTENTS
The Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Directional Reference. . . . . . . . . . . . . . . . . . . . . . . 1-1
Serial Number Plate . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Noise Level Test Results . . . . . . . . . . . . . . . . . . . 1-2
Vibration Level Test Results . . . . . . . . . . . . . . . . . 1-2
Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Customer Support. . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
New Owners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Nomenclature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
THE MANUAL
This operator manual provides the information you need to
correctly operate and maintain the 5515-2 crane.
NOTE: Before you operate the crane, carefully read this
manual completely, so you will understand the
safety instructions and the operation of the controls
and safety equipment. You must comply with all
DANGER, WARNING, and CAUTION notices.
They are for your benefit.
DIRECTIONAL REFERENCE
All references to the right side, left side, front, and rear are
given from the operator’s seat looking in a forward direction.
SERIAL NUMBER PLATE
For easy reference, when contacting the Grove dealer/Crane
Care Customer Service about this crane, record the crane’s
serial number in the space provided in the next column. The
numbers are stamped on the serial plate which is located
behind the operator’s seat. See Figure 1-1. Components,
such as the pump, transmission, engine, axles, etc., have
their own serial plates that will be found on the housing of the
component.
NOTE: The replacement of any part of this product with
anything other than a Crane Care Customer
Service authorized replacement part may
adversely affect the performance, durability, or
safety of this product and will void the warranty.
Crane Care Customer Service assumes no liability
for unauthorized replacement parts which
adversely affect the performance, durability, or
safety of this product.
Serial Number ________________________________
REPORTS
NOTE: A Delivery Report form must be filled out by the
Grove dealer, signed by the purchaser, and
returned to Crane Care Customer Service once the
product is sold and/or put into service. This report
activates the warranty period, assuring that your
claims during the warranty period will be honored
and processed expediently. To guarantee full
warranty service, make sure your Grove dealer has
returned the report to Crane Care Customer
Service. An engine warranty form must also be
filled out, signed and returned to the engine
manufacturer for full warranty coverage.
FIGURE 1-1
Serial Number Plate
p0993
