GROVE Published 1-20-2017, Control # 468-02 8-5
CD5515-2/YB5515-2 OPERATOR MANUAL SPECIFICATIONS
8
Travel Speeds
Two-Wheel Steer
1st gear .................................................................................................6.4 km/hr (4 mph)
2nd gear ................................................................................................11.3 km/hr (7 mph)
3rd gear.................................................................................................21 km/hr (13 mph)
4th gear .................................................................................................34 km/hr (21 mph)
Crane Gross Vehicle Weight .............................................................................13,488 kg (29,735 lb)
FRONT AXLE DRIVE
Type.......................................................................................................International Transmissions Limited
Model.....................................................................................................SD80 - Center Drive Head
REAR AXLE DRIVE
Type.......................................................................................................International Transmissions Limited
Model.....................................................................................................SD80 - Offset Drive Head
REAR AXLE NON-DRIVE
Type.......................................................................................................International Transmissions Limited
Model.....................................................................................................SD80 - Offset with No Drive Head
Operating Dimensions
Two-Wheel Steer
• Outside turning radius
(center line outside tires)............................................................................6.09 m (19' 10.5“)
• Outside turning radius
(end of boom extension, 41’ boom)............................................................7.75 m (25' 5")
(end of boom extension, 50’ boom)............................................................7.66 m (25' 2")
Four-Wheel Steer
• Outside turning radius
(center line outside tires)............................................................................3.84 m (12' 7")
• Outside turning radius
(end of boom extension, 41’ boom)............................................................5.57 m (18' 3")
(end of boom extension, 50’ boom)............................................................5.48 m (18' 0")
Boom Angle
Maximum....................................................................................................69°
Minimum.....................................................................................................0°
OUTRIGGERS
Type ...........................................................................................................Hydraulic
Construction...............................................................................................Welded box
Reference Only
