CONTINUITY TEST FUNCTION
In Auto Check mode, press the "SELECT" key once to select continu-
ity test function.
Connect the test leads across the circuit to be tested.
If the resistance is more than 150 , the built-in buzzer will not
sound, and the display will show " ".
If the resistance is less than about 50 , the buzzer will sound
continuously and the display will change from " " to
" ".
If the resistance is between 50 and 150 , the buzzer may or may
not sound and the display will change with the buzzer's behavior.
Before test, disconnect all power to the circuit to be tested and
discharge all capacitors thoroughly.
NOTE:
model no. 052-0726-0 | contact us 1-800-689-9928
13
OPERATING INSTRUCTIONS
