25
STEP 1 | SHROUD ASSEMBLY ASSEMBLY INSTRUCTIONS & NOTES
PART 6: PL ASTICS ASSEMBLY
ID DESCRIPTION QUANITY
43 Left Front Shroud 1
44 Right Front Shroud 1
45 Rear Shroud 1
ASSEMBLY
Install the weight stack shrouds as shown.
44
45
43
