STEP 1 | BACK PAD ASSEMBLY INSTRUCTIONS & NOTES
ID DESCRIPTION QUANITY
38 Head Rest Assembly 1
39 M10 X 75L BHC 4
40 Back Pad Assembly 1
ASSEMBLY
PART 5: PAD ASSEMBLY
38
39
40
Install the pads as shown.
Tightento27N-m/20ft-lbs.
