D&S Ⅱ DISTORTION & SUSTAINER Ⅱ
FEATURES AND CONTROLS
●Soft type distortion for thick, heavy tone and relaxed natural sustain.
●D&SⅡ produces a wide range of distortion sounds, from warm tone characteristic
of tube amplifier overdrive to aggressive distoetion.
①DISTORTION (Distortion Control)
Controls distortion and sustain level.
Rotate this volume clockwise for
more distortion and sustain.
②TONE (Tone Control)
Controls effect tone. Rotate this vol-
ume clockwise to emphasize middle
and high tone range.
③BALANCE (Balance Control)
Controls output level of effected
tone. Typically output levels of both
normal tone and effected tone
should be adjusted to equal levels.
④ FOOT SWITCH
(Normal / Effect Switch)
Switch for effect on/off. Stepping on
this switch alternately turns effect on
(LED on) and off (LED off).
⑤INDICATOR (LED Indicator)
It lights on when effects are on and
lights off when effects are off. It also
indicates battery condition. Dark or
no LED light indicates the battery is
low or not installed. Replace the
battery.
⑥INSTRUMENT (Instrument Jack)
Input jack to connect to the output of
guitar, other effects or related equip-
ment. The product automatically
turns on when you put a plug into
this jack. Pull out the plug when not
in use.
⑦AMPLIFIER (Amplifier Jack)
Output jack to connect to the input
of amplifier or other effects.
⑧DC IN (Power Input Jack)
A jack to connect AC adaptor.
