-110-
Design & installation Guide For McQuay MDS Multi System
Fault codes here refer to the codes that appear on the remote control. If a host computer is available,
the fault cause is directly displayed.
7.1 Fault Codes for MDS-A/B Series
Fault Codes and Troubleshooting
CHAPTER
7
No. Fault code Description
1E0
System malfunction
2E1 Sensor broken(TH1 discharge temp)
3E2 Sensor broken(TH2 inlet coil 1#)
4E3 Sensor broken(TH3 mid coil 1#)
5E4 Sensor broken(TH4 inlet coil 2#)
6E5 Sensor broken(TH5 mid coil 2#)
7E6 Sensor broken(TH6 inlet coil 3#)
8E7 Sensor broken(TH7 mid coil 3#)
9E8 Sensor broken(TH8 ambient temp..)
10 E9 Sensor broken(TH9 outlet coil)
11 EA Sensor broken(TH10 subcool outlet)
12 EB Sensor broken(TH11 subcool suction)
13 EC Sensor broken(suction)
14 EF Emergency run 36 L0 Super heat too low
15 F0 Outdoor storage malfunction
16 F1 Sensor broken(indoor inlet coil)
17 F2 Sensor broken(indoor mid coil)
18 F3 Sensor broken(indoor outlet coil)
19 F4 Sensor broken(indoor return air )
20 F5 Sensor broken(indoor supply air)
21 F6 Indoor and controller communication malfunction
22 F7
Ambient temp. exceed the limit
23 F8 4wv malfunction
24 F9 Refrigerant leakage
25 FA Controller storage malfunction
26 FB Water pump(indoor drain pump)
27 FC Indoor and outdoor communication malfunction
28 FE
Master and slave communication malfunction
29 H0 Digital comp overload
30 H1 Fixed comp1 overload
31 H2 Fixed comp2 overload
32 H3 Fixed comp3 overload
33 H4 High pressure too high
No. Fault code Description
34 H5
Sensor broken, high pressure
35 H6 Discharge temp. too high
36 L0 Protection for too small degree of overheat
37 L1
Low pressure too low
38 L2 Sensor broken, low pressure
39 10 System malfunction
40 11 Sensor broken(slave TH1 discharge temp.)
41 12 Sensor broken(slave TH2 inlet coil 1#)
42 13 Sensor broken(slave TH3 mid coil 1#)
43 14 Sensor broken(slave TH4 inlet coil 2#)
44 15 Sensor broken(slave TH5 mid coil 2#)
45 16 Sensor broken(slave TH6 inlet coil 3#)
46 17 Sensor broken(slave TH7 mid coil 3#)
47 18 Sensor broken(slave TH8 ambient temp.)
48 19 Sensor broken(slave TH9 outlet coil)
49 1A Sensor broken(slave TH10 subcool outlet)
50 1B Sensor broken(slave TH11 subcool suction)
51 1C Sensor broken(slave TH12 suction)
52 1F Emergency run
53 20 Outdoor storage malfunction
54 27 Ambient temp.. exceed the limit
55 28 4WV malfunction
56 29 Refrigerant leakage
57 30 Digital comp overload
58 31 Fixed comp1 overload
59 32 Fixed comp2 overload
60 33 Fixed comp3 overload
61 34 High pressure too high
62 35 Sensor broken, high pressure
63 36 Discharge temp. too high
64 40 Super heat too low
65 41 Low pressure too low
66 42 Sensor broken, low pressure
