27
At a glance
Instrument cluster
Item Page
1 L Left turn signal indica-
tor lamp
55
2 v ESP
®
warning lamp 372
3 Speedometer
4 Multifunction display 139
5 l Distance warning
lamp
Warning lamp without func-
tion. It illuminates with the ig-
nition on. It should go out
when the engine is running.
6 K Right turn signal indi-
cator lamp
55
7 Coolant temperature
indicator with:
137
• Coolant temperature
warning lamp
371,
391
Item Page
8 Tachometer with: 138
1 Supplemental
Restraint System
(SRS) indicator lamp
64,
375,
375
- Antilock Brake Sys-
tem (ABS) indicator
lamp
366
< Seat belt telltale 78,
373
A High beam headlamp
indicator lamp
131
B Low beam headlamp
indicator lamp
131
9 Main odometer with:
ì•« Gear selector lever
position
139
ì•« Program mode 139
Item Page
a Clock with: 158
; Brake warning lamp,
USA only
368
3 Brake warning lamp,
Canada only
368
ú Engine malfunction in-
dicator lamp,
USA only
369
± Engine malfunction in-
dicator lamp,
Canada only
369
C Roll bar warning lamp
b Fuel display with:
A Fuel reserve warning
lamp
373
c Reset button for:
ì•« Resetting trip odometer 136
ì•« Adjusting instrument
cluster illumination
136
ì•« Confirming new time set-
tings
158
