27
At a glance
Instrument cluster
Item Page
1 L Left turn signal
indicator lamp
2 v ESP
®
warning lamp 345
3 Speedometer
4 Multifunction display 139
5 l Distance warning lamp
Vehicles without Distronic*:
Warning lamp without func-
tion. It illuminates with the
ignition on. It should go out
when the engine is running.
351
6 K Right turn signal
indicator lamp
7 Coolant temperature indica-
tor with:
• Coolant temperature
warning lamp
350
8 Tachometer with:
< Seat belt telltale 351
Item Page
1 Supplemental
Restraint System
(SRS) indicator lamp
353
- Antilock Brake Sys-
tem (ABS) indicator
lamp
344
B Low beam headlamp
indicator lamp, de-
pending on vehicle
production date
55
A High beam headlamp
indicator lamp
130
9 Main odometer with:
앫 Selector lever position 51
앫 Program mode 175
a Clock with: 157
; Brake warning lamp,
USA only
347
3 Brake warning lamp,
Canada only
347
Item Page
ú Engine malfunction in-
dicator lamp, USA
only
348
± Engine malfunction
indicator lamp, Cana-
da only
348
H Combination low tire
pressure/TPMS mal-
function telltale,
USA only
354
Low tire pressure
telltale, Canada only
354
b Fuel display with:
A Fuel tank reserve
warning lamp
351
c Reset button for:
앫 Resetting trip odometer 137
앫 Adjusting instrument
cluster illumination
136
앫 Confirming new time
settings
157
