If the coolant temperature is too high a
display message is shown.
If the coolant temperature rises above
248
‡(120 †), do not drive any further as
this could damage the engine.
Tachometer
The
red band in the tachometer indicates the
engine's overrevving range.
!
Do not drive in the overrevving range, as
this could damage the engine.
The fuel supply is interrupted to protect the
engine when the red band is reached.
Outside temperature display
The outside temperature display is in the
multifunction display
(Y page 196).
G
WARNING
The outside temperature indicator is not
designed to serve as an ice-warning device
and is therefore unsuitable for that purpose.
Indicated temperatures just above the
freezing
point do not guarantee that the road
surface is free of ice. The road may still be icy,
especially in wooded areas or on bridges.
Changes in the outside temperature are
displayed after a short delay.
Speedometer with segments
The segments in the speedometer indicate
which speed range is available.
Cruise control (Y page 159) activated:
The
segments light up from the stored speed
to the maximum speed.
DISTRONIC PLUS (Y page 161) activated:
One or two segments in the set speed range
light up.
DISTRONIC PLUS detects a vehicle in front:
The segments between the speed of the
vehicle
in front and the stored speed light up.
Operating the on-board computer
Overview
The on-board computer is activated as soon
as
you turn the SmartKey to position 1 in the
ignition lock.
You can control the multifunction display and
the settings in the on-board computer using
the buttons on the multifunction steering
wheel.
:
Multifunction display
;
To switch on the Voice Control System;
see the separate operating instructions
=
Right control panel
?
Left control panel
A
Back button
Displays and operation
195
On-board computer and displays
Z
