Belt drive
24
Mechanical components
Introduction of the New V12 Biturbo Engine, M 279 AMG
b
The belt drive is a single-belt system and drives the
ancillaries coolant pump, alternator, ABC pump and
refrigerant compressor.
Due to the high dynamic requirements of the AMG
SPEEDSHIFT PLUS 7G-TRONIC with very short
response times, the belt pulley of the alternator is
fitted with a freewheel.
P13.22-2186-00
Single-belt drive
1 Guide pulley
2 Belt tensioner
3 Refrigerant compressor
4ABC pump
5 Belt pulley
6Alternator
7Coolant pump
