GENERAL INFORMATION
26
Recording Serial Number
It is important to record this number for future reference. The serial
number is located on the outboard as shown.
a - Serial number
b - Model year
c - Model designation
d - Year manufactured
e - Certified Europe Insignia
(as applicable)
135/150/175 Specifications - International
Models 135/150/175
Horsepower 135/150/175
Kilowatts 101/112/130
Full Throttle RPM Range
135 HP - 5200-6400
150/175 HP - 5800-6400
Idle Speed in Neutral Gear
1.
650 RPM
Number of Cylinders 4
Piston Displacement 1,731 cc (105.6 cid)
Cylinder Bore 82 mm (3.23 in.)
Stroke 82 mm (3.23 in.)
Recommended Spark Plug NGK ILFR6G
Spark Plug Gap 0.8 mm (0.0315 in.)
Spark Plug Hex Size 16 mm
Gear Ratio 2.08:1
Recommended Gasoline Refer to Fuel & Oil
Recommended Oil Refer to Fuel & Oil
1. With engine fully warmed up.
