Specifications
Description Specifications
Model 200
Horsepower 200
Kilowatts 149.1
Full throttle RPM range 5150–5650
Idle speed RPM range 900–1000
Number of cylinders 6
Piston displacement 2508 cc (153 in³)
Cylinder bore 88.4 mm (3.500 in.)
Stroke 67.3 mm (2.650 in.)
Spark plug NGK IZFR6J‑11
or NGK IZFR6J
Spark plug gap 1.1 mm (0.043 in.)
Recommended gasoline
Refer to Fuel and Oil
Recommended oil
Refer to Fuel and Oil
Battery rating* (minimum) 1000 marine cranking amps (MCA) or 800 cold
cranking amps (CCA)
Charging system output 60 A
Emission control system Electronic engine control (EC)
*Battery manufacturers may rate and test their batteries to different standards.
MCA, CCA, Ah, and reserve capacity (RC) are the ratings recognized by
Mercury Marine. Manufacturers that use standards different than these, such
as equivalent MCA, do not meet Mercury Marine battery requirements.
GENERAL INFORMATION
eng 27
