OUTBOARD INSTALLATION
106 eng
FILLING THE FUEL SYSTEM
For the initial start of a new engine, or for an engine that ran out of fuel or was
drained of fuel, the fuel system should be filled as follows:
1. Squeeze the fuel line primer bulb until it feels firm.
2. Turn the ignition key switch to the "ON" position for three seconds. This
operates the electric fuel pump.
3. Turn the ignition key switch back to the "OFF" position, and squeeze the
primer bulb again until it feels firm. Turn the ignition key switch to the
"ON" position again for three seconds. Continue this procedure until the
fuel line primer bulb stays firm.
Installation Specifications
a - Minimum transom opening
b - Engine centerline for dual engine ‑ 66.0 cm (26 in.)
Minimum Transom Opening
Single engine 84.8 cm (33‑3/8 in.)
Dual engine 151.8 cm (59‑3/4 in.)
Lifting the Outboard
!
WARNING
Improperly supporting an engine during lifting can result in the engine falling,
causing serious injury or death. Before lifting the engine, verify that the lifting
ring is threaded into the flywheel for a minimum of five turns and that the
hoist has the correct lifting capacity for the engine weight.
To lift the outboard:
1. Remove the cowl from the outboard.
