General Engine Specifications
Crankshaft horsepower
1.
421 kW, 565 HP
Displacement 8.7 L (533 cid)
Cylinder arrangement V8
Bore 113 mm (4.466 in.)
Stroke 108 mm (4.25 in.)
Compression ratio 8.6:1
Alternator 95 amp/1238 watt
Battery requirements Group 31M, 1150 CCA (minimum)
Electrical system 12‑volt negative (–) ground
Ignition type
PCM distributorless, sequential
individual coil
Spark plug type NGK BKR6ES
Spark plug gap 0.9 mm (0.035 in.)
Fuel system
Sequential port electronic fuel
injection
Emission control system Electronic engine control (EC)
Length of Bravo engine package
(transom mount to front of engine)
869 mm (34.19 in.)
Width 838 mm (33.0 in.)
Height (bottom of oil pan to highest part
of the engine which could be the
exhaust system)
919 mm (36.2 in.)
Weight 545 kg (1201 lb)
1. Kilowatts/horsepower rating is in compliance with the SAE J1228/ISO 3046 Standard. Usable power will be
reduced by gear losses.
SPECIFICATIONS
eng 29
