Mercury 565 User Manual

• 25‑amp fuel pump circuit breaker
a - Odd cylinders fuel and ignition
b - Main power relays and diagnostics
c - Even cylinders fuel and ignition
d - 110‑amp fuse
e - 50‑amp main power circuit breaker
f - 25‑amp fuel pump circuit breaker
Remote Controls (Console Mounted Zero Effort)
1. Shift only with the engine at idle speed. Always move to the desired gear
position with a quick, firm motion.
2. The throttle control handle friction is adjustable using a 5/16 in. hex head
wrench; clockwise increases friction.
a - Trim switch
b - Port friction adjustment
c - Starboard friction adjustment
a
b
c
d
e
f
49704
a
b
c
45691
OPERATION
36 eng
