Mercury 6 SERIES User Manual

GEAR HOUSING
90-857138R1 MAY 2000 Page 6-5
Gear Housing (Drive Shaft)
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
– 1 GEAR HOUSING (SHORT)
– 1 GEAR HOUSING (LONG)
1 1 GEAR HOUSING (BASIC)
2 1 BEARING
3 2 PLUG
4 2 GASKET
5 1 BOLT 70 8
6 1 WASHER
7 1 PINION GEAR
8 1 WATER STRAINER
9 1 SCREW 70 8
10 1 BOLT 70 8
11 1 WASHER
12
1 DRIVESHAFT (SHORT)
12
1 DRIVESHAFT (LONG)
13 1 BEARING
14 1 KEY
15 1 GASKET
16
AR SHIM (0.1)
16
AR SHIM (0.15)
17 1 OIL SEAL
18 1 WATER PUMP HOUSING–LOWER
19 1 GASKET
20 1 GUIDE PLATE
21 1 GASKET
22 1 IMPELLER
23 1 LINER
24 1 WATER PUMP HOUSING–UPPER
25 2 SEAL
26 1 HOSE
27 4 BOLT 70 8
28 4 WASHER
29 1 SEAL
30 1 WATER TUBE (SHORT)
31 1 WATER TUBE (LONG)
32 1 GROMMET
33
1 CAM ROD (SHORT)
33
CAM ROD (LONG)
34 1 ROLL PIN
35 1 RETAINER
36 1 BOLT 70 8
37 1 O RING
38 1 BUSHING
39 1 O RING
40 1 CLUTCH CAM
41 1 ROLL PIN
AR = As Required
