Mercury Optimax 115 User Manual

WIRING DIAGRAMS
90-855347R1 JANUARY 1999 Page 2D-21
ENGINE OVER-SPEED PROTECTION SYSTEM
a
a
The system is activated when the engine speed exceeds the maximum allowable RPM.
Anytime the engine over-speed system is activated, the warning horn (a) begins to sound
continuously. The system will automatically reduce the engine speed to within the allow-
able limit.
NOTE: Engine speed should never reach the maximum limit to activate the system unless
the propeller is ventilating, an incorrect propeller is being used, or the propeller is faulty.

Mercury Optimax 115 Specifications

General

Fuel Induction System	2-stage Direct Fuel Injection (DFI)
Alternator Amp	60 amp / 756 watt
Steering	Remote
Cylinders	3
Starting	Electric
Displacement	1.5 L
Bore x Stroke	89 x 76 mm
Shaft Length	20" (508 mm)
Horsepower	115 HP
