Number Fuse amperage
rating
Circuits protected
4 BTN 40 amp Passenger
compartment fuses 1,
2, 6, 12, 13, 7
5 (ABS) 60 amp Anti-lock brake
system (ABS)
6 Cooling fan 40 amp Cooling fan
7 Head — Head lamp relay
8 Not used — —
9 OBD II 10 amp On-board diagnostics
10 Fuel pump 20 amp Fuel pump
11 Head RH 20 amp Passenger side
headlamps
12 Head LH 20 amp Driver side headlamps
CHANGING THE TIRES
Temporary spare tire
information
The temporary spare tire for your
vehicle is labeled as such. It is
smaller than a regular tire and is
designed for emergency use only.
If you use the temporary
spare tire continuously or
do not follow these precautions,
the tire could fail, causing you to
lose control of the vehicle,
possibly injuring yourself or
others.
When driving with the temporary
spare tire, do not:
Roadside emergencies
114
