Insert a new module for the Multi Autolab Cabinet
Figure 25 – The Edit Serial Number application lists the available Autolab devices, identified by serial
number
The frame on the right-hand side of the Edit Serial Number application provides a number
of fields displaying information on the highlighted device. Only the Serial number field can
be edited (the other fields are read-only).
For the Multi Autolab instrument to work properly, the following information needs to be
encoded into
M101 or M204 module installed in the Multi Autolab Cabinet, using
the Edit Serial Number application:
The maximum number of devices that can be controlled by the Edit Serial Number
application is 127!
Unprogrammed M101 modules are identified by a serial number starting with AUT4.
Unprogrammed M204 modules are identified by a serial number starting with AUT5.
21 | Page
