Midea JL1566S-UF User Manual

Service Manual_2018-V1.0
14
N°
PART NAME
N°
PART NAME
1
Top cover
8
Water collector
2
Cooling pilot lamp
9
Heating switch
3
Heating pilot lamp
10
Cooling switch
4
Power pilot lamp
11
Power supply cord
5
Faucet of cold water
12
condenser
6
Faucet of hot water
13
hot water outlet
7
Front carapace
14
Water inlet
2.2 Filter element parameter
滤芯
Filter
类型
Type
参数
Parameters
功能介绍
Features
建议寿命
Recommended life
PP
外形尺寸： 60.5/Φ28*251mm
额定瞬时流量：＞3.0L/min
适用水温：4～38℃
适用水压：0.1～0.4MPa
Dimensions: 60.5/Φ28*251mm
Rated instantaneous flow:> 3.0L / min
Applicable water temperature: 4~38℃
Applicable water pressure: 0.1 ~ 0.4MPa
粗过滤，滤除原水中泥
沙、铁锈、悬浮物等；
Coarse filtration, to filter
out the sediment, rust and
suspended solids in saw
water;
3600L
6 个月
6 months

Midea JL1566S-UF Specifications

General

Brand	Midea
Model	JL1566S-UF
Category	Water Filtration Systems
Language	English
