Service Manual_2018-V1.0
21
8. Take out the pin of the quick joint at the rear of the products side plate’ s, and then take out
the white plug.
9. Insert the water inlet PE pipe in the quick joint, and tighten the pin.
10.The water cooler plug cord into a ground fault interrupter receptacle.
11. After installing, supply power, and use it normally.
12.When installing filter and replace filter please turn off the water and power
supply before installation and replacement.
4.3 Machine installation
1-2. Loosen the screw of the left or right bottom angle
just as the picture shown.
3. Use the screw to fix the bracket on the left or right
bottom angle of the water dispenser.
4. Make a hole on the floor’s or the desk’s surface where
To Next Page
