Midea MRCT-150CWN1-D(C) User Manual

Midea R410A Tropical ClimaCreator Series Rooftop Package 220V 3Ph 60Hz MCAC-RTT6S-201701
121
 Insert the tabs on top of the controller body into the slots at the top of the wall-plate. Press
the bottom of the controller body into the snap on the bottom of the wall-plate. Do not force
the controller onto the wall plate, as the terminal pins may be damaged. If it does not snap
properly, the controller will not work.
 Insert the one AA size alkaline battery, observing the polarity marked inside the battery
compartment.
 Switch on the main power at the panel or furnace.
4. Centralized Controller: MD-CCM03(A) (Optional)
Notes: For some model, the products with factory default cannot be connected with centralized
controller.
3.1 Centralized controller specifications
Model
MD-CCM03(A)
Power Supply Voltage
220~240V 50Hz 1Ph
Ambient Temperature Range
-15°C ～43°C
Ambient Humidity Range
RH40%~RH90%
Performance Features
1. System composition, centralized control.
2. Keywords and general function description.
3. Technical indices and requirements.
4. Indoor unit working status display.
