Midea MRCT-150CWN1-D(C) User Manual

MCAC-RTT6S-201701 Midea R410A Tropical ClimaCreator Series Rooftop Package 220V 3Ph 60Hz
130
until the foregoing switch is turned off. If the foregoing two switches are turned on
concurrently, the emergent shutdown switch shall have preference.
3.5 General display data entries
1) General display data is displayed in all display pages.
 Under the interconnected control of the computer or gateway, the data is displayed in
graphic ( ). Otherwise, no data is displayed.
 If the centralized controller is connected with the functional module for communication,
the data is displayed in graphics ( ). Otherwise, no data is displayed.
 If the centralized controller is connected with the SMS remote control module for
communication, the data is displayed in graphics ( ). Otherwise, no data is displayed.
 If the centralized controller is connected with the telephone remote control module for
communication, the data is displayed in graphics ( ). Otherwise, no data is displayed.
 In normal operation of the centralized controller, the periodical cycle module
communicates with the network interface module, and the data is displayed
dynamically and cyclically: (blank), , , .
 In the centralized control locked status or the keypad locked status, the locking flag ( )
is displayed. After unlocking, it is not displayed. In the centralized controller locked
status or the keypad locked status, the locking flag is displayed constantly. If both of
them are locked concurrently, the locking flag is displayed constantly.
 In the setting page, if the selected air conditioner is in the remote controller locked
status (in case of non-single machine operation, as long as one machine is in the
remote controller locked status, it is deemed the locked status), the flag ( ) is
displayed constantly.
 If all indoor units lock the cooling mode, this flag ( ) will display, and if all indoor units
lock the heating mode, the flag ( ) will display.
2) Data display handling
 Indoor unit code (address) display: display range: 00~63, and with # being luminous
concurrently.

Midea MRCT-150CWN1-D(C) Specifications

General

Cooling Capacity	15000 BTU/h
Power Supply	220-240V, 50Hz
Type	Split Type
Voltage	220-240V
Energy Efficiency Ratio (EER)	3.21
Noise Level (Indoor)	42 dB(A)
Refrigerant	R410A
Noise Level	42 dB(A)

Summary

Part 2 Performances

Detailed Specifications

Comprehensive technical specifications for each model, including electrical and physical data.

Wiring Diagrams

Electrical schematics showing component connections for various models and functionalities.

Cooling Performance Data

Tables detailing cooling capacity under various ambient and indoor temperature conditions.

Electrical Data Summary

Summary of electrical parameters like current, power, and fuse ratings for each model.

Fan Performance Data

Operation Limits

Part 3 Installations

General Information and Precautions

Provides essential safety warnings and general advice before commencing installation.

Installation Steps

Step-by-step instructions for installing the unit on rooftops or ground level.

Electrical Wiring and Power Supply

Covers main power wiring, wire sizes, fuses, and controller wiring requirements.

Start-up Procedures

Checklist of pre-operation checks and steps for initial unit start-up.

Safety Controls and Error Codes

Details system protections, error codes, and troubleshooting flowcharts.

Maintenance Guidelines
