MCAC-RTT6S-201701 Midea R410A Tropical ClimaCreator Series Rooftop Package 220V 3Ph 60Hz
98
0.5h, after 10 hours, increase by 1 hour for each press. If cancel this function, just set it to
4. FOLLOW ME button:
When under cool, heat and auto mode, and press this button, follow me function is active.
Press again, this function is ineffective.
5. AUXIL HEATER button: (Only available for Cooling only with EHK model.)
If press this button in heat mode, electrical heater function become ineffective.
6. RESET button: (Hidden)
Use a 1 mm stick to press in the little hole, then the current setting is canceled. The wired
controller enters into original state.
7. ON/OFF button
When in off state, press this button, the indicator is on, the wired controller enters into on
state, and send setting information to main PCB board. When in on state, press this button,
the indicator is off, and send instruction. If timer-on or timer-off has been set, it cancels this
setting then sends instruction to stop the machine.
8. TEMP ▲ adjust button:
Set indoor temperature up. If press and hold on, it will increase at 1°C (2°F) per 0.5 second.
9. TEMP ▼ adjust button:
Set indoor temperature up. If press and hold on, it will decrease at 1°C (2°F) per 0.5
second.
10. SWING button: (Reserved)
First press, then start swing function; after second press, stop swing.
11. ECO button: (Economy operation, Reserved)
Press this button, and then the unit will operate in economy mode. Press again, this mode
can be exited.
12. FAN SPEED button: (For rooftop packages, it is not available.)
When press this button consecutively, and then the indoor side fan speed will circles as
following:
