2. Specifications
Model
MFA2-76HRN1
MFA2-96HRN1
Power supply
\
220-240V~, 1Ph, 50Hz
220-240V~, 1Ph, 50Hz
Cooling
Capacity
Btu/h
76,000
96,000
W
22,300
28,100
Input
W
7,500
9,600
EER
W/W
2.97
2.93
Heating
Capacity
Btu/h
85,300
106,000
W
25,000
31,100
Input
W
8,300
10,300
COP
W/W
3.01
3.02
Rated input (Indoor unit)
W
700
700
Rated current (Indoor unit)
A
3.0
3.0
Indoor air flow (m
3
/h/CFM)
\
4,300 (2,530)
4,800 (2,824)
Indoor noise level
dB(A)
56
56
Refrigerant type
\
R410A
R410A
Refrigerant control
\
Capillary
Capillary
Fan
Type
\
Centrifugal fan
Centrifugal fan
Motor model (×Qty)
\
YSK300-6 (×1)
YSK300-6 (×1)
Input (Hi/med/lo)
W
570/510/465
600/500/437
Capacitor
\
20μF/450V
25μF/450V
Speed (Hi/med/lo)
r/min
830/750/660
870/760/670
Coil
Type
\
Copper tube and aluminum fin
Copper tube and aluminum fin
Tube size
mm
Ф7
Ф7
No. of rows
\
2
3
Fin spacing
mm
1.5
1.5
Tube pitch× row pitch
mm
21×13.37
21×13.37
Length× height
mm
982×714
982×714
Number of circuits
\
17
25
Controller
\
R51/E
R51/E
Refrigerant pipe (Liquid/ Gas)
mm
Ф9.52/Ф22
Ф9.52/Ф25
Power wire
\
3×2.5mm
2
3×2.5mm
2
Signal wire
\
4×1.0mm
2
4×1.0mm
2
Drain pipe size
mm
Ф41
Ф41
Dimension (W×H×D)
mm
1,200×1,860×420
1,200×1,860×420
Packing (W×H×D)
mm
1,362×2,050×582
1,362×2,050×582
Net/Gross weight
kg
130/145
140/154
Notes:
1. Rated input = Max. input, Rated current = Max. current.
2. Nominal cooling capacities are based on the following conditions:
Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB, 24°C WB; Nominal heating capacities are based on the
following conditions: Indoor temp: 20°CDB, 15°C WB; Outdoor temp: 7°CDB, 6°CWB.
