Midea TempMaker Series User Manual

MCAC-UTSM-2014-03 R410A 380~415V 3Ph 50Hz TempMaker Series Split AC
8
2. Specifications
Model
MTB-76HWN1
MTB-96HWN1
MTB-120HWN1
Power supply
\
220-240V~, 1Ph, 50Hz
Cooling
Capacity
Btu/h
76,000
96,000
120,000
W
22,300
28,100
35,000
Input
W
7,500
9,600
11,900
EER
W/W
2.97
2.93
2.94
Heating
Capacity
Btu/h
85,300
106,000
129,700
W
25,000
31,100
38,000
Input
W
8,300
10,300
12,700
COP
W/W
3.01
3.02
2.99
Rated input (Indoor unit)
W
1,300
1,400
2,000
Rated current (Indoor unit)
A
5.2
5.8
9.0
Indoor air flow (m
3
/h/CFM)
\
4,500 (2,647)
5,100 (3,000)
6,375 (3,750)
Indoor standard ESP
Pa
100
100
100
Indoor noise level
dB(A)
56
56
63
Refrigerant type
\
R410A
R410A
R410A
Refrigerant control
\
Capillary
Fan
Type
\
Centrifugal fan
Centrifugal fan
Centrifugal fan
Motor model (×Quantity)
\
YDK250-4X(×2)
YDK300-4X(×2)
YDK550-4X(×2)
Input (Hi/med/lo)
W
540/450/400
720/605/510
860/750/650
Capacitor
\
12μF/450V
15μF/450V
20μF/450V
Speed (Hi/med/lo)
r/min
860/790/720
1,040/930/825
1,320/1,230/1,140
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Ф7
Ф7
Ф9.52
No. of rows
\
4
4
4
Fin spacing
mm
1.5
1.5
1.5
Tube pitch(a)×row pitch(b)
mm
21×13.37
21×13.37
25.4×22
Length× height
mm
1,202×378
1,202×378
1,202×406.4
Number of circuits
\
14
14
18
Controller
\
KJR-29B
KJR-29B
KJR-29B
Refrigerant pipe (Liquid/ Gas)
mm
Ф9.52/Ф22
Ф9.52/Ф25
Ф12.7/Ф28.6
Power wire
\
3×2.5mm
2
3×2.5mm
2
3×2.5mm
2
Signal wire
\
4×1.0mm
2
4×1.0mm
2
4×1.0mm
2
Drain pipe size
mm
Ф41
Ф41
Ф41
Dimension (W×H×D)
mm
1,366×450×716
1,366×450×716
1,366×450×716
Packing (W×H×D)
mm
1,555×500×875
1,555×500×875
1,555×500×875
Net/Gross weight
kg
94/106
96/108
97/109
Notes:
1. ESP: external static pressure; Rated input = Max. input, Rated current = Max. current.
2. Nominal cooling capacities are based on the following conditions: Indoor temp: 27°CDB, 19°CWB; Outdoor
temp: 35°CDB, 24°C WB; Nominal heating capacities are based on the following conditions: Indoor temp: 20°CDB,
15°C WB; Outdoor temp: 7°CDB, 6°CWB.
