Midea VC Pro Series Engineering Data Book
4 Nomenclature
4.1 Indoor Units
4.1.1 Standard indoor units
M
I
2
-
22
Q1
D
H
N1
○
1
○
2
○
3
○
4
○
5
○
6
○
7
○
8
Legend
No.
Code
Remarks
1
M
Midea
2
I
VRF indoor unit
3
2
The 2nd generation VRF DC indoor unit
4
22
Capacity index (the capacity in kW multiplied by 10)
5
Q1
Indoor unit type
Q1: One-way Cassette
Q2: Two-way Cassette
Q4C: Compact Four-way Cassette
Q4: Four-way Cassette
T2: Medium Static Pressure Duct
T1: High Static Pressure Duct
G: Wall-mounted
DL: Ceiling & Floor
F: Floor Standing
Z: Console
6
D
Series category (D: DC series)
7
H
Power supply
Omit: 1 phase, 220-240V, 50Hz
H: 1 phase, 220-240V, 50/60Hz
8
N1
Refrigerant type (N1: R410A)
4.1.2 Fresh air processing unit
M
I
2
-
280
FA
D
H
N1
○
1
○
2
○
3
○
4
○
5
○
6
○
7
○
8
Legend
No.
Code
Remarks
1
M
Midea
2
I
VRF indoor unit
3
2
The 2nd generation VRF DC indoor unit
4
280
Capacity index (the capacity in kW multiplied by 10)
5
FA
Indoor unit type
FA: Fresh Air Processing Unit
6
D
Series category (D: DC series)
7
H
Power supply
Omit: 1 phase, 220-240V, 50Hz
H: 1 phase, 220-240V, 50/60Hz
8
N1
Refrigerant type (N1: R410A)
