Cleaning and care
31
Reassembling the burner
Place the burner head onto the
burner base so that the ignition
safety device and the ignitor
extend through their respective holes.
The lobe on the burner cap must
fit into the recess on the burner
head. The lobe on the burner head
must fit into the recess on the
burner base.
Replace the burner ring.
Then place the burner caps and
in position.
Ensure parts are reassembled in the
correct order after cleaning.
